Rules for design of graphical symbols for use in the technical documentation—Part 2:Specification for graphical symbols in a computer sensible form,including graphical symbols for a reference library,and requirements for their interchange
MOD IEC 81714-2:2006
全国电气信息结构文件编制和图形符号标准化技术委员会、全国图形符号标准化技术委员会(SAC/TC 27、SAC/TC 59)
GB/ 16901的本部分规定了基准符号库中以计算机电子文件格式描述的图形符号的要求及其在计算机辅助工具间的交换要求。
本部分适用于基准符号库可用作技术文件编制、计算机辅助工具间文件和图形符号库的交换基础。
本部分不包含交换所需的物理文件格式规范。
