Chinese Standard: GB/T 16902.2-2008

Rules for the presentation of graphical symbols for use on equipment—Part 2:Form and use of arrows

MOD  ISO 80416-2:2001

全国图形符号标准化技术委员会

GB/T 16902的本部分规定了用箭头表示运动、速度、力、功能或尺寸的基本原则。本部分确定的箭头用于设备用图形符号或图形符号要素。
本部分适用于创建新的原形符号或修改现行的图形符号。

This standard is the original Chinese electronic standard.
If you need translation, please contact email: ChineseStandardsLibraryS001@gmail.com.
After you successfully purchase, we will send the electronic version of this standard to your email address
