Design recommendations for bevel gears
Scope of Application：
This document provides application information for bevel gears and hypoid gears, with geometry, load capacity, and accuracy tolerances respectively based on ISO 23509, ISO 10300 (all parts), and ISO 17485. It offers relevant data on the application, manufacturing, strength, and efficiency of bevel gears for designers' reference. The term "bevel gear" is used for the design of straight bevel gears, spiral bevel gears, zerol bevel gears, and hypoid gears. If the content of this document pertains to one or more (but not all) of these types, it will be specifically noted.
Note: Appendix NA provides various expressions for the classification and terminology of bevel gears. The target tooth profile described in this document can be processed using various methods, ensuring general applicability without implying any specific process. This document is intended for experienced gear designers who can rely on their knowledge and background to make reasonable choices for the required values. This document is not suitable for general technical personnel.
Basic information
Standard No：GB/Z 43147-2023
Standard Name： 锥齿轮设计建议
English Name：Design recommendations for bevel gears
Standard Status：In force
Release Date：2023-09-07
Effective Date：2024-04-01
Language of Publication：Simplified Chinese
Publication Information
Number of pages：40
Number of words：72 K
Other Information
Technical Committees：National Technical Committee for Standardization of Gears (SAC/TC 52)
Proposed Unit：National Technical Committee for Standardization of Gears (SAC/TC 52)
Application Dept：State Administration for Market Supervision and Administration, State Standardization Administration
