Vocabulary of graphical symbols for use on electrical equipment
Scope of Application：
This document defines a collection of terms (glossary) in the field of graphical symbols for equipment, as well as related fields, used in IEC, ISO, ITU, and national standard publications. To clarify certain terms, annotations and/or modifications have been made.
Basic information
Standard No：GB/Z 43345-2023
Standard Name： 电气设备用图形符号词汇
English Name：Vocabulary of graphical symbols for use on electrical equipment
Standard Status：In force
Release Date：2023-11-27
Effective Date：2024-06-01
Language of Publication：Simplified Chinese
Publication Information
Number of pages：16
Number of words：21 K
Other Information
Technical Committees：National Technical Committee for Standardization of Electrical Information Structure, Documentation and Graphical Symbols (SAC/TC 27)
Proposed Unit：National Technical Committee for Standardization of Electrical Information Structure, Documentation and Graphical Symbols (SAC/TC 27)
Application Dept：State Administration for Market Supervision and Administration, State Standardization Administration
