Guidance for determination of clearances,creepage distances and
requirements for solid insulation for equipment with a rated voltage
above 1 000 V AC and 1 500 V DC,and up to 2 000 V AC and 3 000 V DC.
Standard in brief
Scope of Application：
This document serves as a technical specification to provide guidance to technical committees for the determination of insulation fits for equipment with rated voltages from 1 000 V to 2 000 V ac and from 1 500 V to 3 000 V dc. For equipment with rated voltages up to 1 000 V AC and 1 500 V DC and with higher or lower internal voltages for insulation fits, the relevant requirements are given in IEC 60664 1. This document applies to equipment for use at altitudes up to 2 000 m above sea level and provides guidance for use at higher altitudes. This document specifies guidelines for electrical clearances, creepage distances and solid insulation for equipment to meet safety requirements, including relevant electrical test methods. NOTE: Since the requirements for functional insulation are not part of the safety requirements, they are not specified accordingly. This document is not concerned with determining the following types of distances: - insulation through liquids; - through gases other than air; - through compressed air.
Basic information
Standard No：GB/Z 43963-2024
Standard Name： 确定额定电压在交流1 000 V以上至2 000 V，直流1 500 V以上至3 000 V间设备的电气间隙、爬电距离的数值以及对固体绝缘要求的指南
English Name：Guidance for determination of clearances,creepage distances and
requirements for solid insulation for equipment with a rated voltage
above 1 000 V AC and 1 500 V DC,and up to 2 000 V AC and 3 000 V DC.
Standard Status：To be implemented
Release Date：2024-04-25
Effective Date：2024-11-01
Language of Publication：Simplified Chinese
Publication Information
Number of pages：28
Number of words：41 K
Other Information
Technical Committees：National Technical Committee for Standardization of Insulation Fitting for Low Voltage Equipment (SAC/TC 417)
Proposed Unit：China Electrical Appliance Industry Association (CEAIA)
Application Dept：State Administration for Market Supervision and Administration, State Standardization Administration
