Connectors for electrical and electronic equipment—Product requirements—Part 8-100:Power connectors—Detail specification for 2-pole or 3-pole power plus 2-pole signal shielded and sealed connectors with plastic housing for rated current of 20 A
Standard in brief
Scope of Application：
本文件规定了电子和电气设备用2芯、3芯20 A功率加2芯信号塑料外壳屏蔽密封连接器(以下简称“电连接器”)的外形尺寸、接口尺寸、技术参数、性能要求和试验方法等。
本文件适用于电子和电气设备领域，额定电压不大于交流750 V或直流1 000 V、额定电流20 A有密封和屏蔽要求的电气连接场合。
Basic information
Standard No：GB/T 18501.8100-2025
Standard Name：电子和电气设备用连接器 产品要求 第8-100部分：电源连接器2芯、3芯20 A功率加2芯信号塑料外壳屏蔽密封连接器详细规范
English Name：Connectors for electrical and electronic equipment—Product requirements—Part 8-100:Power connectors—Detail specification for 2-pole or 3-pole power plus 2-pole signal shielded and sealed connectors with plastic housing for rated current of 20 A
Standard Status：现行
Release Date：2025-05-30
Effective Date：2025-12-01
Language of Publication：中文简体
Standard Classification
ICS Number：31.220
CCS Number：L23
Related Standards
Referenced Standards：GB/T 131-2006,GB/T 3956-2008,GB/T 4210-2015,GB/T 5169.11-2017,ISO 6508-1:2015,ISO 11469,IEC 60068-1,IEC 60352-1,IEC 60352-2,IEC 60352-3,IEC 60352-4,IEC 60352-5,IEC 60352-6,IEC 60352-7,IEC 60512-1-1,IEC 60512-1-2,IEC 60512-2-1,IEC 60512-2-2,IEC 60512-2-5,IEC 60512-2-6,IEC 60512-3-1,IEC 60512-4-1,IEC 60512-5-1,IEC 60512-5-2,IEC 60512-6-3,IEC 60512-6-4,IEC 60512-7-1,IEC 60512-9-1,IEC 60512-9-2,IEC 60512-11-1,IEC 60512-11-3,IEC 60512-11-4,IEC 60512-11-6,IEC 60512-11-9,IEC 60512-11-10,IEC 60512-11-11,IEC 60512-11-12,IEC 60512-13-1,IEC 60512-13-5,IEC 60512-15-1,IEC 60512-15-6,IEC 60512-16-5,IEC 60529:1989,IEC 60999-1,IEC 60999-2,IEC 61076-1:2006,IEC 61984:2008,IEC 62430,IEC Guide 109
Adopted Standards：IEC 61076-8-100:2020
Adopted Standard Name：《电子和电气设备用连接器 产品要求 第8-100部分:电源连接器 2芯、3芯20 A功率加2芯信号塑料外壳屏蔽密封连接器详细规范》
Adoption Level：IDT
Publication Information
Number of pages：40
Number of words：60 K
Format：大16
Edition：1
Color Pages：0
Electronic Version：Yes
Color Images：No
Print Publication Date：2025-05-01
Standard Revision Information
Has Amendment：No
Other Information
Application Dept：国家市场监督管理总局、国家标准化管理委员会
Standard Type：CN
Standard Attribute：GB
Other Standard Number：18501.8100
Drafter：陈学永、朱茗、韩见强、宋凯亮、郭辉、张磊、张韩斌、段锐、沙文瀚、王飞、舒南翔
Drafting Organization：中航光电科技股份有限公司、中国电子技术标准化研究院、奇瑞新能源汽车股份有限公司、安徽江淮汽车集团股份有限公司
Management Organization：全国电子设备用机电元件标准化技术委员会(SAC/TC 166)
Proposing Department：中华人民共和国工业和信息化部
